Chicago Pneumatic QRS 5.5 Rotary Screw Air Compressor

Chicago Pneumatic, Model QRS 5.5, comes with Tri-voltage motor with optional tank and refrigerated air dryer.

Operating Pressure

• 116-145 psig
• Flow Rate: 18.7-16.8 cfm (model/pressure dependent)
• Total absorbed power at full load (116 psi): 5.1Kw, (145 psi):5.5Kw, Motor
• Power Supply: 208–230/460V or 575V, 3-phase, 60Hz

Cooling Type

• Air-cooled, oil-injected rotary screw Sound Level: 62 dBA
• Duty Cycle: 100% continuous operation

Controller

• Analog, electro-pneumatic, Dimensions (Base Mount): 24 x 24 x 37 in
• Dimensions (Tank Mount): 56 x 23 x 49 in
• Weight: 298-474 lbs. (configuration dependent)
